Model: GHI-256
Max. Board Size: ATX M/B (Max. to 12" x 9.6")
System Board Type: Core i, Core2Duo, Core2Quad, Pentium, Dual Xeon, AMD 64, Dual Opteron, Athlon


  Product Information
Standard: EIA RS-310C 19" Rackmount Standard
Construction: Heavy Duty Cold Rolled Electroplated Steel
Color: Black (Standard), Beige or Custom
Drive Capacity: 2x 3.5" HDD
Power Supply (Optional): 2U Single up to 300W ATX P/S (Rear Installation) Max. Depth 205mm
Cooling Units: 3x (80mm = 42.5CFM ea.) Fans
Connector Port (Front): 2x USB Ports
Expansion Slot (Optional): 3x Horizontal PCI Slots or 7x Low Profile PCI Slots
Indicators: LEDs for Power ON/OFF, LAN, HDD Activity
Switch: Power ON/OFF, System Reset
Dimensions(W x H x D): 483 x 88 x 357mm (19.0" x 3.5" x 14.1")
Weight: 8.8 kgs / 19.4 lbs
Cu. ft.: 2.0
Carton Size: 57 x 20.3 x 50.0 (22.4" x 8.0" x 19.7")
Humidity: 5% - 95% Non-condensing
Product Applications:


  Optional Accessories
HDD Drive Accessories:
Slide Rails:
Chassis Height: 2U
