| Model: |
GHI-256 |
| Max. Board Size: |
ATX M/B (Max. to 12" x 9.6") |
| System Board Type: |
Core i, Core2Duo, Core2Quad, Pentium, Dual Xeon, AMD 64, Dual Opteron, Athlon |
| Standard: |
EIA RS-310C 19" Rackmount Standard |
| Construction: |
Heavy Duty Cold Rolled Electroplated Steel |
| Color: |
Black (Standard), Beige or Custom |
| Drive Capacity: |
2x 3.5" HDD |
| Power Supply (Optional): |
2U Single up to 300W ATX P/S (Rear Installation) Max. Depth 205mm |
| Cooling Units: |
3x (80mm = 42.5CFM ea.) Fans |
| Connector Port (Front): |
2x USB Ports |
| Expansion Slot (Optional): |
3x Horizontal PCI Slots or 7x Low Profile PCI Slots |
| Indicators: |
LEDs for Power ON/OFF, LAN, HDD Activity |
| Switch: |
Power ON/OFF, System Reset |
| Dimensions(W x H x D): |
483 x 88 x 357mm (19.0" x 3.5" x 14.1") |
| Weight: |
8.8 kgs / 19.4 lbs |
| Cu. ft.: |
2.0 |
| Carton Size: |
57 x 20.3 x 50.0 (22.4" x 8.0" x 19.7") |
| Humidity: |
5% - 95% Non-condensing |
| Product Applications: |
|
| HDD Drive Accessories: |
|
| Slide Rails: |
|
| Chassis Height: |
2U
|
|
|
