You are here : Home  |  Product  |  Rackmount Chassis  |  2U  |  GHI-29B


More Product Pictures
Download File
Model: GHI-29B
Max. Board Size: EATX M/B (Max.to 12" x 13") SSI EEB 3.0
System Board Type: Core i, Core2Duo, Core2Quad, Pentium, Dual Xeon, AMD 64, Dual Opteron, Athlon


  Product Information
Standard: EIA RS-310C 19" Rackmount Standard
Construction: Heavy Duty Cold Rolled Electroplated Steel
Color: Black (Standard), Beige or Custom
Drive Capacity 24x Hot Swap 2.5" Drive Trays
Drive Interface: SATA
Power Supply: 2U Single or Redundant ATX P/S (Rear Installation) Max. Depth 300mm
Cooling Units: 4x (80mm = 42.5CFM ea.) Fans
Riser Card: 2U Riser Card
Connector Port (front): 1x USB Ports
Indicators: LEDs for Power ON/OFF, HDD Power/Acess, LAN
Buttons: Power ON/OFF, System Reset
Dimensions (W x H x D): 483 x 88 x 590mm (19" x 3.5" x 23.2")
Weight: 16.0 kgs/ 35.3 lbs
Cu. ft.: 3.5
Carton Size: 58.5 x 23.5 x 73.0 (23.0" x 9.3" x 28.7")
Humidity: 5% - 95% Non-condensing


  Optional Accessories
HDD Drive Accessories:
Slide Rails:
Chassis Height: 2U
