Input / Output Ratings

Model 　Input(AC) 　Output(DC) Voltage Frequency Current Watt Load +5V +3.3V +12V -5V -12V 5Vsb EVP-G400P 90-264V 47-63Hz 9A/4A 400W+400W Max. 24A 24A 32A N/A 0.8A 3.5A Min. 1A 1A 1A N/A 0A 0.1A Max. Comb. └ 160W ┘       17.5W      Note 1: Maximum continuous total DC output power should not exceed 400W.

Features, General Spec., Agency Requirements

80+ silver Efficiency With PMBus (OP)
Kintron PMBus SOLUTION

Electrical Specification

Regulation, Ripple & Noise
Item / Output		+5V	+3.3V	+12V	-5V	-12V	5Vsb
Load Regulation		±5%	±5%	±5%	±10%	±5%	±5%
Cross Requlation		±5%	±5%	±5%	±10%	±5%	±5%
Line Regulation		±1%	±1%	±1%	±1%	±1%	±1%
Ripple & Noise		50mV	50mV	120mV	100mV	120mV	50mV
