| Model: |
GHI-221 |
| Max. Board Size: |
EATX (12" x 13") |
| System Board Type: |
Core i, Core2Duo, Core2Quad, Pentium, Dual Xeon, AMD 64, Dual Opteron, Athlon |
| Standard: |
EIA RS-310C 19" Rackmount Standard |
| Construction: |
Heavy Duty Cold Rolled Electroplated Steel |
| Color: |
Black (Standard), Beige or Custom |
| Drive Bays: |
4x 5.25" & 2x 3.5"HDD & 1x 3.5"FDD or 6 Storage Module & 2x 3.5"HDD & 1x 3.5"FDD |
| Power Supply: |
2U Single up to 510W or Redundant up to 400W ATX P/S (Rear Installation) Max. Depth 300mm |
| Cooling Units: |
4x (80mm = 42.5CFM ea.) |
| Expansion Slot: |
|
| Connector Port (front): |
2 x USB Ports |
| Indicators: |
|
| Buttons: |
Power ON/OFF Momentary (Dimple), System Reset |
| Crossbar: |
|
| Thermal Card: |
NA |
| Front Door(s): |
Single Door With 2 Thumbscrew and
Removeable Door |
| Air Filter: |
|
| Dimensions(W x H x D): |
483 x 88 x 650mm (19" x 3.5" x 25.6") |
| Weight: |
14.9 kgs / 32.9 lbs |
| Cu. ft.: |
|
| Carton Size: |
58.8 x 25.5 x 82.5 (23.2" x 10" x 32.5") |
| Humidity: |
5% - 95% Non-condensing |
| Product Applications: |
|
| HDD Drive Accessories: |
|
| Slide Rails: |
|
| Chassis Height: |
2U |
|
|
