| Model: |
GHI-170 |
| Max. Board Size: |
2x (6" x 13") |
| System Board Type: |
Core i, Core2Duo, Core2Quad, Pentium, Dual Xeon, AMD 64, Dual Opteron, Athlon |
| Standard: |
EIA RS-310C 19" Rackmount Standard |
| Construction: |
Heavy Duty Cold Rolled Electroplated Steel |
| Color: |
Black (Standard), Beige or Custom |
| Drive Bays: |
2x 3.5"HDD |
| Power Supply: |
U 200~250W ATX P/S, Max.Depth 190mm |
| Cooling Units: |
6x (40 x 20mm = 7CFM ea.) & 2x (40 x 28mm=15.3CFM ea.) Fans |
| Expansion Slot: |
2x Horizontal PCI Slot |
| Connector Port (front): |
4x USB Ports |
| Indicators: |
|
| Buttons: |
Power ON/OFF Momentary, System Reset |
| Crossbar: |
|
| Thermal Card: |
NA |
| Front Door(s): |
Single Door With 1 Thumbscrew |
| Air Filter: |
None |
| Dimensions(W x H x D): |
483 x 44 x 542mm (19" x 1.7" x 21.3") |
| Weight: |
10.2 kgs / 22.5 lbs |
| Cu. ft.: |
|
| Carton Size: |
68.5 x 18.5 x 57.3 (27" x 7.3" x 22.6") |
| Humidity: |
5% - 95% Non-condensing |
| Product Applications: |
|
| HDD Drive Accessories: |
|
| Slide Rails: |
|
| Chassis Height: |
1U |
|
|
