| Model: |
GHI-142 |
| Max. Board Size: |
EATX (12" x 13") |
| System Board Type: |
Core i, Core2Duo, Core2Quad, Pentium, Dual Xeon, AMD 64, Dual Opteron, Athlon |
| Standard: |
EIA RS-310C 19" Rackmount Standard |
| Construction: |
Heavy Duty Cold Rolled Electroplated Steel |
| Color: |
Black (Standard), Beige or Custom |
| Drive Bays: |
1x Slim CD-ROM & 1x Slim FDD
(or 1x5.25" CD-ROM) & 2x 3.5" HDD |
| Power Supply: |
1U Redundant up to 400W ATX
P/S(Front Installation) |
| Cooling Units: |
7x (40x28 mm = 15.3CFM ea.) Fans |
| Expansion Slot: |
1x Horizontal PCI Slot |
| Connector Port (front): |
2x USB Ports |
| Indicators: |
|
| Buttons: |
Power ON/OFF Momentary (Square), System
Reset, Buzzer Reset |
| Crossbar: |
|
| Thermal Card: |
NA |
| Front Door(s): |
|
| Air Filter: |
None |
| Dimensions(W x H x D): |
483 x 44 x 700mm(19" x 1.7" x 27.6") |
| Weight: |
14.5kgs / 32.0lbs |
| Cu. ft.: |
|
| Carton Size: |
59.4 x 18.2 x 81.8(23.4" x 7.2" x 32.2") |
| Humidity: |
5% - 95% Non-condensing |
| Product Applications: |
|
| HDD Drive Accessories: |
|
| Slide Rails: |
|
| Chassis Height: |
1U |
|
|
