| Model: |
GHI-107A |
| Max. Board Size: |
ATX (12" x 10.5") |
| System Board Type: |
Core i, Core2Duo, Core2Quad, Pentium, Dual Xeon, AMD 64, Dual Opteron, Athlon |
| Standard: |
EIA RS-310C 19" Rackmount Standard |
| Construction: |
Heavy Duty Cold Rolled Electroplated Steel |
| Color: |
Black (Standard), Beige or Custom |
| Drive Bays: |
1x Slim CD-ROM & 1x 2.5" HDD (for 12" x 10.5" M/B) or 1x 3.5"HDD(for 12" x 9.6" M/B) |
| Power Supply: |
1U up to 400W ATX P/S, Max. Depth 190mm |
| Cooling Units: |
3x (40x28mm = 15.3CFM ea.) Fans |
| Expansion Slot: |
1x Horizontal PCI Slot |
| Connector Port (front): |
2x USB Ports |
| Indicators: |
|
| Buttons: |
Power ON/OFF, System Reset |
| Crossbar: |
|
| Thermal Card: |
NA |
| Front Door(s): |
|
| Air Filter: |
None |
| Dimensions(W x H x D): |
483 x 44 x 386mm (19" x 1.7" x 15.2") |
| Weight: |
7.3 kgs / 16.1 lbs |
| Cu. ft.: |
|
| Carton Size: |
52 x 19 x 59 (20.5" x 7.5" x 23.2") |
| Humidity: |
5% - 95% Non-condensing |
| Product Applications: |
|
| HDD Drive Accessories: |
|
| Slide Rails: |
|
| Chassis Height: |
1U |
|
|
GHI-107A.pdf
