| Board: |
Support EATX M/B (12" x 10.5") SSI EEB 3.0 |
| Drive Capacity: |
2x 5.25"(160mm) & 1x 3.5"FDD |
| Power Supply (Optional): |
1U Single up to 500W ATX P/S(Mid Installation) Max. Depth 190mm |
| Cooling: |
1x (120mm= 90CFM) With Removable Air Filter Fan |
| Expansion Slots: |
7x Slots |
| Connector Port (Front): |
2x USB Ports |
| Front Door: |
|
| Air Filter: |
Inside Front Panel (Washable) |
| Thermal Management Card: |
GHA-CO04 |
| LCD Size: |
|
| play Color: |
|
| Luminance: |
|
| Indicators: |
LEDs for Power ON/OFF, HDD Activity, Fan, Temperature, LAN |
| Hold Down Bar: |
Flexible Hold Down Bar Designed |
| Switch: |
Power ON/OFF, System Reset, Buzzer Reset |
| Dimensions: |
350 x 177 x 411mm (13.8" x 7" x 16.2") |
| Cuft: |
3.1 |
| GW: |
12.9 kgs / 28.5 lbs |
| Carton Size: |
49 x 32.4 x 55.8 (19.3" x 12.8" x 22") |
| Humidity: |
5% - 95% Non-condensing |
GHB-081
