| Board: |
Support 8-slot Passive Backplane |
| Drive Capacity: |
2x 5.25" & 1x 3.5" & 1x 3.5"HDD |
| Power Supply (Optional): |
PS/2 Size Single 250~400W or Redundant 230~400W P/S(Rear Installation) Max. Depth 190mm |
| Cooling: |
1x (120mm = 90CFM ea.) Fan |
| Expansion Slots: |
8x Slots |
| Connector Port (Front): |
2x USB Ports (Optional) |
| Front Door: |
Single Door With 1 Thumbscrew |
| Air Filter: |
Inside Front Panel (Washable) |
| Thermal Management Card: |
GHA-CO01 |
| LCD Size: |
|
| play Color: |
|
| Luminance: |
|
| Indicators: |
LEDs for Power ON/OFF, HDD Activity, Fan, Temperature |
| Hold Down Bar: |
Flexible Hold Down Bar Designed |
| Switch: |
Power ON/OFF, System Reset, Buzzer Reset |
| Dimensions: |
350x177x421mm(13.8" x 7" x16.6") |
| Cuft: |
3.1 |
| GW: |
15 kgs / 33.1 lbs |
| Carton Size: |
49 x 32.4 x 55.8(19.3" x 12.8" x 22") |
| Humidity: |
5% - 95% Non-condensing |
GHB-080
