| Board: |
Supports 6-slot Passive Backplane |
| Drive Capacity: |
1x 5.25", 1x 3.5" HDD, 1x 3.5" FDD, & 1x 3.5" HDD (Optional) |
| Power Supply (Optional): |
PS/2 Size Single or Mini Redundant ATX PSU |
| Cooling: |
1x (120mm = 90CFM) Fan |
| Expansion Slots: |
6x Slots |
| Connector Port (Front): |
2x USB 2.0 Ports (Optional: USB 3.0 Ports) |
| Air Filter: |
Inside Front Panel (Washable) |
| Thermal Management Card: |
GHA-CO04 |
| Indicators: |
LEDs for Power ON/OFF, HDD Activity, Fan, Temperature |
| Hold Down Bar/Cross Bar: |
Flexible Hold Down Bar Designed; With Plastic Screw-down Type |
| Switch: |
Power ON/OFF Momentary (Rocker), System Reset, Buzzer Reset |
| Dimensions: |
307x177x412 mm(12"x7"x16.2") |
| Cuft: |
2.9 |
| GW: |
11.4 kgs / 25.1 lbs |
| Carton Size: |
45.5 x 32.4 x 55.8 (17.9" x 12.8" x 22") |
| Humidity: |
5% - 95% Non-condensing |
GHB-062-6.pdf
