GHI-581


More Product Pictures
Download File

Specifications

Model: GHI-581
Max. Board Size: EATX (12" x 13")
System Board Type: Core i, Core2Duo, Core2Quad, Pentium, Dual Xeon, AMD 64, Dual Opteron, Athlon



  Product Information
Standard: EIA RS-310C 19" Rackmount Standard
Construction: Heavy Duty Cold Rolled Electroplated Steel
Color: Black (Standard), Beige or Custom
Drive Bays: 1x 5.25", 1x Slim FDD & 22x 3.5" Hot Swappable Trays & 1x 2.5"HDD & 2x 3.5"HDD (Optional)
Power Supply: 2x Redundant up to 500W ATX P/S ea. (Rear Installation) Max. Depth 275mm
Cooling Units: 3x (120mm = 90CFM ea.) Fans & 1x (80mm = 42.5CFM ea.) Fan & 2x (60mm = 23.5CFM ea.) Fans
Expansion Slot: 7 Slots
Connector Port (front): 2x USB Ports
Indicators:
Buttons: Power ON/OFF Momentary (Dimple), System Reset, Buzzer Reset
Crossbar:
Thermal Card:
Front Door(s): Single Door with 2 Thumbscrews (Removable)
Air Filter:
Dimensions(W x H x D): 483x 222 x 650mm(19"x8.7"x25.6")
Weight: 33.5 kgs / 73.9 lbs
Cu. ft.: 6.8
Carton Size: 85.5 x 37 x61 (33.7" x 14.6" x 24")
Humidity: 5% - 95% Non-condensing
Product Applications:



  Optional Accessories
HDD Drive Accessories:
Slide Rails:
Chassis Height: 5U
