| Model: |
GHI-580 |
| Max. Board Size: |
EATX (12" x 13") |
| System Board Type: |
Core i, Core2Duo, Core2Quad, Pentium, Dual Xeon, AMD 64, Dual Opteron, Athlon |
| Standard: |
EIA RS-310C 19" Rackmount Standard |
| Construction: |
Heavy Duty Cold Rolled Electroplated Steel |
| Color: |
Black (Standard), Beige or Custom |
| Drive Bays: |
1x Slim CD-ROM & 1x Slim FDD & 24x 3.5"Swappable, 2x 2.5"HDD & 2 x 3.5"HDD(Optional) |
| Power Supply: |
2x Redundant up to 500W ATX P/S ea. (Rear Installation) Max. Depth 275mm |
| Cooling Units: |
3x (120mm = 90CFM ea.) Fans & 1x (80mm = 42.5CFM ea.) Fan & 2x (60mm = 23.5CFM ea.) Fans |
| Expansion Slot: |
7 Slots |
| Connector Port (front): |
2x USB Ports |
| Indicators: |
|
| Buttons: |
Power ON/OFF Momentary (Dimple), System Reset, Buzzer Reset |
| Crossbar: |
|
| Thermal Card: |
|
| Front Door(s): |
Single Door with 2 Thumbscrews(Removable) |
| Air Filter: |
|
| Dimensions(W x H x D): |
483 x 222 x 650mm (19" x 8.7" x 25.6") |
| Weight: |
33.5 kgs / 73.9 lbs |
| Cu. ft.: |
6.8 |
| Carton Size: |
85.5 x 37 x 61(33.7" x 14.6" x 24") |
| Humidity: |
5% - 95% Non-condensing |
| Product Applications: |
|
| HDD Drive Accessories: |
|
| Slide Rails: |
|
| Chassis Height: |
5U |
|
|
GHI-580.pdf
