| Model: |
GHI-104 |
| Max. Board Size: |
EATX (12" x 13") |
| System Board Type: |
Core i, Core2Duo, Core2Quad, Pentium, Dual Xeon, AMD 64, Dual Opteron, Athlon |
| Standard: |
EIA RS-310C 19" Rackmount Standard |
| Construction: |
Heavy Duty Cold Rolled Electroplated Steel |
| Color: |
Black (Standard), Beige or Custom |
| Drive Bays: |
(Option A): 1x 5.25" & 1x 3.5" & 2x 3.5"HDD (Option B): 2x 5.25" & 1x 3.5" |
| Power Supply: |
1U Single up to 500W ATX P/S(Mid Installation) Max. Depth 225mm |
| Cooling Units: |
3x(40 x 20mm) Fans(7.0CFM ea.) & 2x (40 x28mm) Fans(15.3CFM ea.)(GHI-104) or 5x (40 x 28mm = 15.3CFM ea.) Fans (GHI-104DX) |
| Expansion Slot: |
1x Horizontal PCI Slot |
| Connector Port (front): |
2x USB Ports |
| Indicators: |
|
| Buttons: |
Power ON/OFF, System Reset |
| Crossbar: |
|
| Thermal Card: |
NA |
| Front Door(s): |
Single Door with 1 Thumbscrew |
| Air Filter: |
None |
| Dimensions(W x H x D): |
483x44x605mm(19" x 1.7" x 23.8") |
| Weight: |
10.0kgs / 22.1lbs |
| Cu. ft.: |
|
| Carton Size: |
74.5 x 18.5 x 57.3 (29.3" x 7.3" x 22.6") |
| Humidity: |
5% - 95% Non-condensing |
| Product Applications: |
|
| HDD Drive Accessories: |
|
| Slide Rails: |
|
| Chassis Height: |
|
|
|
GHI-104.pdf
