GHI-791


More Product Pictures
Download File

Specifications

Model: GHI-791
Max. Board Size: 13"x16"
System Board Type:

  Product Information
Standard: EIA RS-310C 19" Rackmount Standard
Construction: Heavy Duty Cold Rolled Electroplated Steel
Color: Black (Standard), Beige or Custom
Drive Bays: SATA, SCSI320 , Multilane SATA or SAS
Power Supply: 1U Redundant up to 1650W ATX P/S (Rear Installation) Max. Depth 300mm
Cooling Units: 2x (80mm = 42.5CFM ea.) & 4x (90mm = 51.0CFM ea.) & 2x (120mm = 40.2CFM ea.) Fans
Expansion Slot: 7 slots
Connector Port (front): 2x USB Ports
Indicators:
Buttons: Power ON/OFF Momentary (Rocker), System Reset, Buzzer Reset
Crossbar:
Thermal Card:
Front Door(s): Single Door With 2 Thumbscrews
Air Filter:
Dimensions(W x H x D): 483 x 311 x 666mm (19" x 12.24" x 26.2")
Weight: 40.9 kgs / 90.2 lbs
Cu. ft.: 9.1
Carton Size: 85 x 49.4 x 61.5 (33.5" x 19.5" x 26.2")
Humidity: 5% - 95% Non-condensing
Product Applications:

  Optional Accessories
HDD Drive Accessories:
Slide Rails:
Chassis Height: 7U
