GH-620


More Product Pictures
Download File

Specifications

Model: GH-620
Max. Board Size: GHP-2020GHP-2020SGHP-2220GHP-2220GGHP-2220Q
System Board Type: Passive Backplane



  Product Information
Standard: EIA RS-310C 19" Rackmount Standard
Construction: Heavy Duty Cold Rolled Electroplated Steel
Color: Black (Standard), Beige or Custom
Drive Bays: 7x 5.25" & 1x 3.5"
Power Supply: PS/2 Size Single up to 700W or Horizontal Redundant up to 550W or Mini Redundant up to 500W ATX P/S(Rear Installation)
Cooling Units: Hot Swappable 4x (90mm = 51CFM ea.) Fans
Expansion Slot: 19/20 Slots
Connector Port (front):
Indicators:
Buttons: Power ON/OFF Momentary or AT (Pushbutton), System Reset, Buzzer Reset
Crossbar:
Thermal Card:
Front Door(s): Single Door With Keylock
Air Filter: Inside Front Door (Washable)
Dimensions(W x H x D): 483 x 267 x 671mm (19" x 10.5" x 26.4")
Weight: 29.0 kgs / 64.0 lbs
Cu. ft.: 7.7
Carton Size: 61 x 41.8 x 85.5 (24" x 16.5" x 33.7")
Humidity: 5% - 95% Non-condensing
Product Applications:



  Optional Accessories
HDD Drive Accessories:
Slide Rails:
Chassis Height: 6U
