| Model: |
GHI-4F1 |
| Max. Board Size: |
EATX (12" x 13") |
| System Board Type: |
Core i, Core2Duo, Core2Quad, Pentium, Dual Xeon, AMD 64, Dual Opteron, Athlon |
| Standard: |
EIA RS-310C 19" Rackmount Standard |
| Construction: |
Heavy Duty Cold Rolled Electroplated Steel |
| Color: |
Black (Standard), Beige or Custom |
| Drive Bays: |
1 x Slim CD-ROM & 1x 3.5" FDD & 2x 3.5" HDD |
| Power Supply: |
PS/2 Size Single up to 700W or Mini Redundant up to 500W ATX P/S (Rear Installation) Max. Depth 230mm |
| Cooling Units: |
2x (90mm = 51CFM ea.) & 2x (60mm = 23.5CFM ea.) Fans(Optional) |
| Expansion Slot: |
7 Slots or 14/15 Slots (SR) |
| Connector Port (front): |
2xUSB Ports |
| Indicators: |
|
| Buttons: |
Power ON/OFF Momentary (Rocker), System Reset |
| Crossbar: |
|
| Thermal Card: |
|
| Front Door(s): |
|
| Air Filter: |
|
| Dimensions(W x H x D): |
483 x 177 x 447mm (19" x 7" x 17.6") |
| Weight: |
14.2 kgs / 31.3 lbs |
| Cu. ft.: |
4.4 |
| Carton Size: |
61.8 x 34 x 59 (24.3" x 13.4" x 23.2") |
| Humidity: |
5% - 95% Non-condensing |
| Product Applications: |
|
| HDD Drive Accessories: |
|
| Slide Rails: |
|
| Chassis Height: |
4U |
|
|
GHI-4F1.pdf
