| Model: |
GHI-479 |
| Max. Board Size: |
ATX (12" x 9.6") |
| System Board Type: |
Core i, Core2Duo, Core2Quad, Pentium, Dual Xeon, AMD 64, Dual Opteron, Athlon |
| Standard: |
EIA RS-310C 19" Rackmount Standard |
| Construction: |
Heavy Duty Cold Rolled Electroplated Steel |
| Color: |
Black (Standard) or Custom |
| Drive Bays: |
2x 3.5" & 6x 5.25" |
| Power Supply: |
PS/2 Size Single or Mini Redundant ATX PSU (Rear Installation) Max. Depth 220mm |
| Cooling Units: |
2x (80mm = 35CFM ea.) & 2x (60mm = 23.5CFM ea.) Fans |
| Expansion Slot: |
7 slots(ATX); Optional 14 or 15 slots(SR) |
| Connector Port (front): |
2x USB 2.0 Ports; Optional 2x USB 3.0 Ports |
| Indicators: |
|
| Buttons: |
Power ON/OFF Momentary (Pushbutton), System Reset |
| Crossbar: |
|
| Thermal Card: |
|
| Front Door(s): |
Single Door With Keylock |
| Air Filter: |
|
| Dimensions(W x H x D): |
483 x 177 x 510mm (19" x 7" x 20.1") |
| Weight: |
17.8 kgs / 39.3 lbs |
| Cu. ft.: |
4.9 |
| Carton Size: |
59.1 x 34 x 68.8 (23.3" x 13.4" x 27.1") |
| Humidity: |
5% - 95% Non-condensing |
| Product Applications: |
|
| HDD Drive Accessories: |
|
| Slide Rails: |
|
| Chassis Height: |
4U |
|
|
GHI-479.pdf
