| Standard: |
EIA RS-310C 19" Rackmount Standard |
| Construction: |
Heavy Duty Cold Rolled Electroplated Steel |
| Color: |
Black (Standard), Beige or Custom |
| Drive Bays: |
2x 5.25" & 1x 3.5"FDD & 8x 3.5" Swappable Trays |
| Power Supply: |
2U Single or Redundant ATX PSU (Rear Installation) Max. Depth 300mm |
| Cooling Units: |
3x (80mm = 42.5CFM ea) & 2x (60mm = 23.5CFM ea.) Fan |
| Expansion Slot: |
7 Slots |
| Connector Port (front): |
2x USB Ports |
| Indicators: |
LEDs for Power ON/OFF, HDD Activity, LAN |
| Buttons: |
Power ON/OFF Momentary (Pushbutton), System Reset |
| Crossbar: |
N/A |
| Thermal Card: |
N/A |
| Front Door(s): |
Double Doors With Thumb Twist Keylock |
| Air Filter: |
N/A |
| Dimensions(W x H x D): |
483 x 177 x 624mm (19" x 7" x 24.5") |
| Weight: |
19.1 kgs / 42.1 lbs |
| Cu. ft.: |
4.8 |
| Carton Size: |
59.5 x 29.2 x 77.5 (23.4" x 11.5" x 30.5") |
| Humidity: |
5% - 95% Non-condensing |
| Product Applications: |
|
GHI-A31.pdf
